Philips Semiconductors
UM_1SPP
BGB203 BT 2.0 Serial Port Profile Module User’s Guide
if no response was retrieved from the remote device. Following the
above output, the response will be the result code (either OK or
ERROR ).
Example:
AT+BTRNM=0123456789AB
+BTRNM: 0123456789AB, “BGB203 – 1SPP”
OK
OK
AT+BTRNM=123456789ABC
+BTRNM: 0123456789ABC, NO RESPONSE
+BTSDP – perform remote service discovery
Description:
This command is used to query a remote Bluetooth device’s local
services (not the local Bluetooth device’s local services) using the
Service Discovery Protocol (SDP). This function only returns services
that utilize the RFCOMM protocol (i.e. it does not return services that use
L2CAP as the transport protocol).
Format:
AT+BTSDP=<BDADDR>, <Profile Filter>
where,
<BDADDR> is the 12 digit ASCII coded hexadecimal Bluetooth
Device address of the remote Bluetooth device to discover
services. This value is required to be 12 digits (note that this
value is not preceded with the “ \x ” or the “ \X ” prefix).
<Profile Filter> is an optional integer value that represents the
profiles that should be searched for. If this parameter is not
present then all services will be returned. The values for the
profile filter are given in the following table (note that multiple
profiles can be searched for by logically OR’ing the values
together (or by integer adding the values together)).
? Koninklijke Philips Electronics N.V. 2005
All rights are reserved. Reproduction in whole or in part is prohibited without the prior
written consent of the copyright owner. The information presented in this document does
not form part of any quotation or contract, is believed to be accurate and reliable and may
be changed without notice. No liability will be accepted by the publisher for any
consequence of its use. Publication thereof does not convey nor imply any license under
patent- or other industrial or intellectual property rights.
Date of release:21 Dec 2005
Published in The Netherlands
